ElecProof
FOR ELECTRICAL ENGINEERING FIRMS

Verified draft models for arc-flash studies, in 48 hours.

Photo: electrical switchgear, via Wikimedia Commons — public domainDiagram: illustrative draft · DWG E-101 · Rev A

Send your field photos and existing drawings. Get back a draft model where every value links to its source — and anything uncertain is flagged for your review, never guessed.

You review everythingEvery value cites its sourceYour PE signs the study
01 · THE PROBLEM

Up to half the work can happen before the calculations begin.

Photographing equipment. Reading worn nameplates. Reconciling old drawings against what is actually in the field. Before a model can be trusted, the inputs have to be found, transcribed and checked.

02 · WHERE WE SIT

AI reads. Engineers seal.

ElecProof transcribes study inputs with visible evidence. It never calculates the study, never stamps the result and never guesses silently. The engineer stays responsible for every decision.

03 · HOW IT WORKS

A shorter path from field evidence to a reviewable draft.

From field evidence to a reviewable draft in four stages. The schematic below draws the whole workflow as a one-line: upload, extraction, review, verified draft.

Arc-flash input workflow / schematicDraft route · engineer controlled
INPUT / 01

Field photos + drawings

Raw evidence enters intact.

Photos · one-lines · schedules
READ / 02

AI extraction

Values are transcribed, not calculated.

Transcribed — never calculated
REVIEW / 03

Engineer review

Flags and conflicts stay visible.

Flags + conflicts stay visible
OUTPUT / 04

Verified draft model

Ready for your calculation workflow.

Draft only · your PE signs
Proof standard

Extract with visible evidence, or ask a human. Never guess silently.

The standard is simple: if a value cannot be traced to evidence, it does not quietly enter the model as fact.

What we do

  • Every value links back to its source.
  • Low-confidence reads are flagged, not filled.
  • Photo-vs-drawing conflicts surface side by side.
  • You decide every flagged item.

What we never do

  • Never invent a missing value.
  • Never compute incident energy, PPE or fault current.
  • Never stamp the study. Your PE does.
  • Never bury uncertainty inside a clean-looking output.
Pilot pricing

Flat pricing, in the open.

ElecProof is onboarding a small number of pilot firms. Pricing is flat — no per-user fees.

  • $249/monthStarter — up to 3 studies a month, 2 seats.
  • $549/monthProfessional — up to 10 studies a month, 5 seats.
  • $1,199/monthScale — up to 30 studies a month, unlimited seats.
  • $500first studyOr start with one study, handled white-glove — judge the output on your own work before any subscription.

Every plan includes

  • Every value linked to its source photo or drawing.
  • Photo-vs-drawing conflicts flagged side by side, not smoothed over.
  • Low-confidence reads flagged for your review — never filled in by guessing.
  • A reviewable draft in 48 hours, once usable evidence arrives.
  • Your PE reviews and signs the study. ElecProof prepares inputs; it does not stamp engineering work.
Data handling

Your data

Your field photos, drawings, and study records are private to your account. Only your account can open them.

  • Files are stored with Appwrite Cloud in the United States. The application is hosted on Vercel.
  • We do not sell your data.
  • You can request an export or a deletion of your data at any time: hello@elecproof.tech.
Before production

What engineers want to know before trusting ElecProof on a study

Direct answers about scope, responsibility, evidence and where this tool fits in an existing engineering workflow.

Talk to us
The study
What does an arc-flash study cost?
Most arc-flash studies cost between $6,000 and $15,000. A study for a mid-size facility averages $12,000 to $15,000. A small commercial building with a single service can run $3,500 to $6,000, and a large industrial site can exceed $50,000. The price is driven by the number of buses and panels, the condition of the existing drawings, and how much field data collection the study needs. Your firm prices the study; ElecProof is priced separately — $500 for a first study, then $249 to $1,199 a month.
How long does an arc-flash study take?
Most studies take 3 to 16 weeks from the field visit to the stamped report. The calculations are the fast part once the data is clean; collecting, transcribing and reconciling the equipment data is what consumes the schedule. ElecProof returns a reviewable draft model within 48 hours of receiving usable field photos and drawings, which removes the transcription and reconciliation wait at the front of the study.
What data does an arc-flash study need?
Nameplate and settings data for every significant device in the system: transformer kVA, primary and secondary voltage and impedance; breaker manufacturer, frame size, trip rating and settings; fuse type and ampere rating; cable size, material and length; panel schedules; motor horsepower and full-load amps; and the available fault current from the serving utility. The existing one-line diagram and panel schedules are the starting documents, where they exist.
How does the 48-hour timeline work?
The 48 hours starts when usable field photos and drawings arrive. You receive a reviewable draft model: extracted values, each one linked to the photo or drawing it came from, with photo-vs-drawing conflicts and unreadable values flagged for your decision. Scope and source quality are checked before a pilot timeline is confirmed.
How does this relate to NFPA 70E data requirements?
NFPA 70E 130.5 requires an arc-flash risk assessment before work on or near energized equipment at 50 volts or above, and requires it to be reviewed at intervals not exceeding five years and after major changes to the system. The assessment is only as good as the equipment data behind it. ElecProof prepares and traces that data; it does not interpret the standard for you or replace the qualified engineer responsible for the study.
Trust & responsibility
Can AI do the study alone?
No. ElecProof prepares draft inputs with visible provenance and flags. Engineers review the data, run the calculations and make the professional judgments.
Who is responsible for the final study?
Your engineering team remains responsible. The PE reviews and seals the study; ElecProof does not stamp or approve engineering work.
What software is used for arc-flash studies?
The short-circuit, coordination and arc-flash calculations are run in SKM PowerTools, ETAP or EasyPower, using the IEEE 1584 method. Those tools start from a model — and the model starts from field data that someone has to collect and enter. ElecProof covers that data-collection step, before the analysis software.
Does ElecProof replace SKM or ETAP?
No. ElecProof reads and structures source evidence. Your existing engineering software performs the calculations. You receive an Excel/CSV data pack with an import guide for your analysis software; ElecProof does not generate native SKM or ETAP project files.
What happens when a nameplate is unreadable?
The field stays flagged and linked to the source photo. Your reviewer can resolve it from another source or send it back for better field evidence.
Getting started
What do we need to start?
A bounded study, the available field photos and drawings, and a person on your team who can review flagged inputs and source conflicts.
What do we get back?
A verified draft model: every extracted value linked to the photo or drawing it came from, photo-vs-drawing conflicts shown side by side for your decision, and unreadable or low-confidence values flagged rather than filled in. The model is delivered as a reviewable draft plus an Excel/CSV data pack with an import guide for SKM, ETAP or EasyPower.
Still unsure? Talk to us
Send us the study you are planning at hello@elecproof.tech and we will tell you plainly whether ElecProof fits it — and what a pilot would look like if it does.

Run one real study through it — see if you trust the output.

ElecProof — TransmittalForm EP-T1 · Rev A
Item
One real study — yours
Route
Field photos + drawings → verified draft
Turnaround
48 hours, once usable evidence arrives
Status
Awaiting stamp
Submit for pilotStamps the sheet · opens an email to hello@elecproof.tech

DRAFT ONLY — YOUR PE REVIEWS AND SIGNS EVERY STUDY
